• Roking dog structure.
• One of the most popular impact wrenches in the market.
• Suitable for screw and unscrew work of big truck and lorry.Also can be used in the maintenance of bus and general equipments of large machines.

Appearance patent

lmitations must be studied

Patent number:201330021511.8

Product Specifications

Model ZM-1280 ZM-1290 ZM-1295
Free Speed 3600r.p.m 3300r.p.m 3200r.p.m
Bolt Capacity 50mm 50mm 50mm
Max.Torque 3260N.m 3800N.m 4180N.m
Air Inlet 1/2" 1/2" 1/2"
Air Pressure 8-12kg/cm² 8-12kg/cm² 8-12kg/cm²
Anvil Length 8" 8" 8"
Applied Torsion 1300-2850N.m 1300-3500N.m 1500-3800N.m
Air Consumption 0.73 m³/min 0.78 m³/min 0.80 m³/min
Net Weight 18.5kgs 19.0kgs 20.0kgs
Qtylctn 1pcs 1pcs 1pcs
Carton Measurement 730*245*195mm 730*245*195mm 730*245*195mm
